Haynes Wire Manufacturer, Supplier, and Stockists in India

Haynes Wire is a premium alloy wire that is widely utilized in various industrial applications due to its exceptional mechanical and thermal properties. Composed primarily of nickel and chromium, this wire exhibits remarkable strength and resistance to high temperatures, making it ideal for environments where durability and reliability are paramount. Industries such as aerospace, chemical processing, and oil and gas frequently employ Haynes Wire for components that require both resilience and the ability to withstand corrosive environments.

The unique composition of Haynes Wire grants it outstanding resistance to oxidation and corrosion, which is essential for applications in harsh environments. Its high melting point enables it to maintain structural integrity even under extreme temperatures, making it suitable for use in gas turbines and exhaust systems. Furthermore, its excellent fatigue strength allows for extended operational lifetimes, reducing the need for frequent replacements and maintenance, which is a significant advantage in industrial manufacturing.

In addition to its mechanical and thermal properties, Haynes Wire is known for its versatility in fabrication. It can be easily formed into various shapes and sizes, including coils, rods, and custom components, allowing manufacturers to adapt it to specific project requirements. This adaptability, combined with its superior performance characteristics, positions Haynes Wire as a preferred choice for engineers and designers seeking reliable materials for complex applications.

The advantages of using Haynes Wire extend beyond its physical properties; its cost-effectiveness in the long run is notable. While the initial investment may be higher than that of standard wires, the durability and reduced maintenance costs associated with Haynes Wire lead to lower overall operational expenses. This makes it a smart investment for industries that prioritize quality and longevity in their manufacturing processes.

Specification Table

Specification	Haynes Wire
Material Grade	Haynes 230
Standards	ASTM B163, ASME SB165
Form	Coils, Rods, Sheets
Size Range	0.5 mm – 5 mm
Wall Thickness	0.5 mm – 20 mm
Length	Single Random, Double Random
Density	8.44 g/cm³
Tensile Strength	965 MPa
Yield Strength (0.2% Offset)	690 MPa
Elongation	30%
Hardness	Rockwell B90
Melting Point	1350°C
Corrosion Resistance	Excellent in marine & chemical environments
Applications	Oil & Gas, Chemical Processing, Aerospace
Exported To	USA, Canada, Germany, UAE

Chemical Properties Table

Chemical Element	Haynes Wire
Nickel (Ni)	52%
Chromium (Cr)	22%
Iron (Fe)	9%
Manganese (Mn)	1%
Carbon (C)	0.08%
Silicon (Si)	0.5%
Copper (Cu)	0.5%
Titanium (Ti)	0.5%

Mechanical Properties Table

Mechanical Property	Haynes Wire
Tensile Strength (MPa)	965
Yield Strength (0.2% Offset, MPa)	690
Elongation (%)	30
Hardness (Rockwell)	B90
Modulus of Elasticity (GPa)	200
Poisson's Ratio	0.31
Shear Modulus (GPa)	77
Density (g/cm³)	8.44
Reduction of Area (%)	50
Ultimate Tensile Strength (MPa)	1100
